如下所示：
#!/usr/bin/python
#coding:utf-8
import MySQLdb
import time,datetime
#zabbix数据库信息：
zdbhost = '172.16.8.200'
zdbuser = 'zabbix'
zdbpass = 'zabbix'
zdbport = 3306
zdbname = 'zabbix'
#生成文件名称：
xlsfilename = 'zabbix.xls'
#需要查询的key列表 [名称，表名，key值，取值，格式化，数据整除处理]
keys = [
['CPU核心数','trends_uint','system.cpu.num','avg','',1],
['CPU平均空闲值','trends','system.cpu.util[,idle]','avg','%.2f',1],
['CPU最小空闲值','trends','system.cpu.util[,idle]','min','%.2f',1],
['CPU5分钟负载','trends','system.cpu.load[percpu,avg5]','avg','%.2f',1],
['物理内存大小(单位G)','trends_uint','vm.memory.size[total]','avg','',1048576000],
['可用平均内存(单位G)','trends_uint','vm.memory.size[available]','avg','',1048576000],
['可用最小内存(单位G)','trends_uint','vm.memory.size[available]','min','',1048576000],
['swap总大小(单位G)','trends_uint','system.swap.size[,total]','avg','',1048576000],
['swap平均剩余(单位G)','trends_uint','system.swap.size[,free]','avg','',1048576000],
['根分区总大小(单位G)','trends_uint','vfs.fs.size[/,total]','avg','',1073741824],
['根分区平均剩余(单位G)','trends_uint','vfs.fs.size[/,free]','avg','',1073741824],
['进入最大流量（单位Kbps）','trends_uint','net.if.in[eth0]','max','',1000],
['进入平均流量（单位Kbps）','trends_uint','net.if.in[eth0]','avg','',1000],
['出去最大流量（单位Kbps）','trends_uint','net.if.out[eth0]','max','',1000],
['出去平均流量（单位Kbps）','trends_uint','net.if.out[eth0]','avg','',1000],
]
class ReportForm:
def __init__(self):
'''打开数据库连接'''
self.conn = MySQLdb.connect(host=zdbhost,user=zdbuser,passwd=zdbpass,port=zdbport,db=zdbname)
self.cursor = self.conn.cursor(cursorclass=MySQLdb.cursors.DictCursor)
#生成zabbix哪个分组报表
self.groupname = 'zabbix server'
#获取IP信息：
self.IpInfoList = self.__getHostList()
def __getHostList(self):
'''根据zabbix组名获取该组所有IP'''
#查询组ID:
sql = '''select groupid from groups where name = '%s' ''' % self.groupname
self.cursor.execute(sql)
groupid = self.cursor.fetchone()['groupid']
#根据groupid查询该分组下面的所有主机ID（hostid）：
sql = '''select hostid from hosts_groups where groupid = %s''' % groupid
self.cursor.execute(sql)
hostlist = self.cursor.fetchall()
#生成IP信息字典：结构为{'119.146.207.19':{'hostid':10086L,},}
IpInfoList = {}
for i in hostlist:
hostid = i['hostid']
sql = '''select host from hosts where status = 0 and hostid = %s''' % hostid
ret = self.cursor.execute(sql)
if ret:
IpInfoList[self.cursor.fetchone()['host']] = {'hostid':hostid}
return IpInfoList
def __getItemid(self,hostid,itemname):
'''获取itemid'''
sql = '''select itemid from items where hostid = %s and key_ = '%s' ''' % (hostid, itemname)
if self.cursor.execute(sql):
itemid = self.cursor.fetchone()['itemid']
else:
itemid = None
return itemid
def getTrendsValue(self,type, itemid, start_time, stop_time):
'''查询trends_uint表的值,type的值为min,max,avg三种'''
sql = '''select %s(value_%s) as result from trends where itemid = %s and clock >= %s and clock <= %s''' % (type, type, itemid, start_time, stop_time)
self.cursor.execute(sql)
result = self.cursor.fetchone()['result']
if result == None:
result = 0
return result
def getTrends_uintValue(self,type, itemid, start_time, stop_time):
'''查询trends_uint表的值,type的值为min,max,avg三种'''
sql = '''select %s(value_%s) as result from trends_uint where itemid = %s and clock >= %s and clock <= %s''' % (type, type, itemid, start_time, stop_time)
self.cursor.execute(sql)
result = self.cursor.fetchone()['result']
if result:
result = int(result)
else:
result = 0
return result
def getLastMonthData(self,type,hostid,table,itemname):
'''根据hostid,itemname获取该监控项的值'''
#获取上个月的第一天和最后一天
ts_first = int(time.mktime(datetime.date(datetime.date.today().year,datetime.date.today().month-1,1).timetuple()))
lst_last = datetime.date(datetime.date.today().year,datetime.date.today().month,1)-datetime.timedelta(1)
ts_last = int(time.mktime(lst_last.timetuple()))
itemid = self.__getItemid(hostid, itemname)
function = getattr(self,'get%sValue' % table.capitalize())
return function(type,itemid, ts_first, ts_last)
def getInfo(self):
#循环读取IP列表信息
for ip,resultdict in zabbix.IpInfoList.items():
print "正在查询 IP:%-15s hostid:%5d 的信息！" % (ip, resultdict['hostid'])
#循环读取keys，逐个key统计数据：
for value in keys:
print "\t正在统计 key_:%s" % value[2]
if not value[2] in zabbix.IpInfoList[ip]:
zabbix.IpInfoList[ip][value[2]] = {}
data = zabbix.getLastMonthData(value[3], resultdict['hostid'],value[1],value[2])
zabbix.IpInfoList[ip][value[2]][value[3]] = data
def writeToXls2(self):
'''生成xls文件'''
try:
import xlsxwriter
#创建文件
workbook = xlsxwriter.Workbook(xlsfilename)
#创建工作薄
worksheet = workbook.add_worksheet()
#写入第一列：
worksheet.write(0,0,"主机".decode('utf-8'))
i = 1
for ip in self.IpInfoList:
worksheet.write(i,0,ip)
i = i + 1
#写入其他列：
i = 1
for value in keys:
worksheet.write(0,i,value[0].decode('utf-8'))
#写入该列内容：
j = 1
for ip,result in self.IpInfoList.items():
if value[4]:
worksheet.write(j,i, value[4] % result[value[2]][value[3]])
else:
worksheet.write(j,i, result[value[2]][value[3]] / value[5])
j = j + 1
i = i + 1
except Exception,e:
print e
def __del__(self):
'''关闭数据库连接'''
self.cursor.close()
self.conn.close()
if __name__ == "__main__":
zabbix = ReportForm()
zabbix.getInfo()
zabbix.writeToXls2()
以上这篇ZABBIX3.2使用python脚本实现监控报表的方法就是小编分享给大家的全部内容了，希望能给大家一个参考，也希望大家多多支持脚本之家。
